硬件工程师们，随着物联网、智能家居、可穿戴设备等行业的迅猛发展，对硬件的小型化、低功耗和高性能要求与日俱增。低压直流电机驱动正顺应这一时代潮流，成为推动这些新兴领域创新发展的核心技术之一。它不仅要适配各种微小型电机，还要在复杂的应用场景中提供稳定可靠的动力支持。了解并掌握低压直流电机驱动的最新技术和应用，已成为我们在这个快速发展的行业中保持竞争力的必备技能。下面，就让我们紧跟趋势，一探究竟。今天介绍的是国企矽塔的电机驱动驱动。
一、单通道的低压有刷直流电机驱动
| 型号 | 最低工作电压(V) | 最高工作电压(V) | 持续电流
(A) |
峰值电流
(A) |
欠压保护 | 过温保护 | 过流保护 | 封装 | Notes |
| SA6208 | 4.5 | 18.0 | 0.2 | 0.3 | Yes | Yes | SOP8 | ||
| SA6208A | 2.7 | 18.0 | 0.2 | 0.3 | Yes | Yes | SOP8 | ||
| SA116L | 0.8 | 6.0 | 0.6 | 1.2 | Yes | Yes | SOT23-6 | ||
| SA113 | 2.0 | 7.0 | 1.0 | 2.0 | Yes | Yes | SOT23-6 | ||
| SA113A | 2.0 | 8.5 | 1.0 | 2.0 | Yes | Yes | SOT23-6 | ||
| SA8301B | 2.0 | 7.5 | 1.0 | 2.0 | Yes | Yes | SOT23-6 | ||
| SA8310 | 2.0 | 7.5 | 1.0 | 2.0 | Yes | Yes | SOP8, DFN2X2-8 | ||
| SA8301P | 1.5 | 6.5 | 1.2 | 2.0 | Yes | Yes | SOP8 | 集成低功耗LDO | |
| SA8307 | 1.5 | 9.5 | 1.2 | 2.5 | Yes | Yes | SOP8 | ||
| SA1511 | 2.0 | 7.5 | 1.2 | 2.0 | Yes | Yes | SOT23-6 | ||
| SA8311M | 2.7 | 15.0 | 1.2 | 2.5 | Yes | Yes | SOP8 | ||
| SA9110 | 2.7 | 12.0 | 1.2 | 2.0 | Yes | Yes | SOP8 | ||
| SA9110A | 2.7 | 16.0 | 1.2 | 2.0 | Yes | Yes | SOP8 | ||
| SA116 | 2.0 | 7.0 | 1.3 | 2.5 | Yes | Yes | SOT23-6 | ||
| SA8301A | 1.8 | 7.5 | 1.3 | 2.5 | Yes | Yes | SOT23-6 | ||
| SA1107 | 2.7 | 11.0 | 1.3 | 4.0 | Yes | Yes | Yes | SOP8 | 集成低功耗LDO |
| SA116H | 1.6 | 10.0 | 1.5 | 2.5 | Yes | Yes | SOT23-6 | ||
| SA8301S | 2.0 | 7.5 | 1.5 | 2.0 | Yes | Yes | SOP8 | ||
| SA8308 | 1.5 | 9.5 | 1.5 | 3.0 | Yes | Yes | SOP8 | ||
| SA8311S | 2.7 | 15.0 | 1.5 | 3.5 | Yes | Yes | SOP8 | ||
| SA8316 | 2.7 | 16.0 | 1.5 | 2.5 | Yes | Yes | Yes | SOT23-6 | |
| SA8317 | 2.7 | 15.0 | 1.5 | 2.5 | Yes | Yes | Yes | SOP8 | |
| SA1037 | 2.7 | 11.0 | 1.5 | 4.0 | Yes | Yes | Yes | SOP8 | |
| SA8301 | 2.0 | 7.5 | 1.8 | 2.5 | Yes | Yes | SOP8 | ||
| SA8311 | 2.7 | 15.0 | 2.0 | 3.5 | Yes | Yes | SOP8 | ||
| SA8319 | 3.0 | 16.0 | 2.0 | 3.0 | Yes | Yes | Yes | SOP8 | |
| SA8303 | 2.0 | 7.0 | 2.2 | 4.0 | Yes | Yes | DFN3X3-8, SOP8, ESOP8 | ||
| SA8313 | 2.7 | 10.0 | 2.3 | 4.0 | Yes | Yes | ESOP8 | ||
| SA8317E | 2.7 | 15.0 | 2.5 | 3.5 | Yes | Yes | Yes | SOP8 | |
| SA8318 | 3.0 | 12.0 | 2.6 | 5.5 | Yes | Yes | Yes | SOP8 | |
| SA8304S | 1.0 | 6.5 | 2.7 | 6.0 | Yes | Yes | SOP8 | ||
| SA8304 | 2.0 | 7.0 | 3.0 | 6.0 | Yes | Yes | ESOP8 | ||
| SA8315 | 2.7 | 10.0 | 3.0 | 7.0 | Yes | Yes | Yes | ESOP8 | |
| SA8305 | 1.0 | 6.5 | 3.5 | 10.0 | Yes | Yes | ESOP8 | ||
| SA8306 | 2.0 | 7.0 | 3.5 | 6.0 | Yes | Yes | ESOP8 |
这部分就是只有1通道的低压有刷直流电机驱动，按持续电流升序排列，表格都有比较详细的介绍，需要规格书的话就后台联系我所需要的型号即可。
二、双通道的低压有刷直流电机驱动
| 型号 | 最低工作电压(V) | 最高工作电压
(V) |
持续电流
(A) |
峰值电流(A) | 欠压保护 | 过温保护 | 过流保护 | 封装 | Notes |
| SA8302 | 2.0 | 7.0 | 1.6/1.6 | 3.0/3.0 | Yes | Yes | SOP16 | ||
| SA8302B | 1.5 | 6.5 | 1.2/1.2 | 2.5/2.5 | Yes | Yes | SOP16 | 集成低功耗LDO | |
| SA8302S | 2.0 | 6.5 | 1.7/1.7 | 3.0/3.0 | Yes | Yes | SOP16 | ||
| SA2626L | 1.5 | 6.0 | 2.6/2.6 | 6.0/6.0 | Yes | Yes | SOP16 | ||
| SA3030L | 1.5 | 6.0 | 3.0/3.0 | 10.0/10.0 | Yes | Yes | ESOP16 | ||
| SA2020 | 2.7 | 10.0 | 2.0/2.0 | 4.0/4.0 | Yes | Yes | SOP16 | ||
| SA2121 | 2.7 | 10.0 | 2.1/2.1 | 4.0/4.0 | Yes | Yes | DIP16 | ||
| SA2222 | 2.7 | 10.0 | 2.2/2.2 | 4.5/4.5 | Yes | Yes | ESOP16 | ||
| SA2626 | 2.7 | 15.0 | 2.6/2.6 | 6.0/6.0 | Yes | Yes | SOP16 | ||
| SA8312 | 2.7 | 12.0 | 1.7/1.7 | 3.0/3.0 | Yes | Yes | SOP16 | ||
| SA8312S | 2.7 | 8.5 | 1.5/1.5 | 3.0/3.0 | Yes | Yes | SOP16 | ||
| SA8314 | 2.7 | 12.0 | 1.7/1.7 | 3.0/3.0 | Yes | Yes | Yes | SOP16 |
这部分就是有2通道的低压有刷直流电机驱动，表格都有比较详细的介绍，需要规格书的话就后台联系我所需要的型号即可。
